Commercial Pastry Mixer Machine

MOQ:1 set /Sets
Brand:Gelgoog Machinery
Certification: CE
Supply Ability: 100 sets/Per Month
PAY METHOD: WEST UNION L/C T/T CASH
Warranty Time: 12 Months
LOADING PORT: Qingdao
Country Of Origin: China

Features

Features:
1. This makes the batter for the system to produce the wafers, but it can also make the flour batter for other usage. This system constitutes of: batter mixing tank and batter storage tank and pumps and fittings for transferring batter. Batter mixing tank, batter transfer pump and pipes and fittings all adopt Stainless Steel 304 food quality material. Good tightness is required for electric control cabinet; Capacity of the batter will be 25kgs of flour per batch which can be converted into about 65 kgs batter within 5 minutes of mixing. 2. 2. 2. Batter Mixer will have flat type lid to cover the mixing units. There is a new added batter filter.
3. The machine is the mixing system, the first technology processing equipment in wafer manufacturing. It adopts the separate delivery and automatic circulation system.
4. Material: the machine frame is made of steel with international standard and the cover adopts imported 304 stainless steel plate with thickness of 1.2mm,also can customize it into other thickness.

Instruction:
1. Material :all adopts 304 Stainless Steel ,SEW Motor ,Siemens Touch Screen.
2.Auto-weighing of wafer and ingredients,Auto-control of temperature after setting ,it will finish the whole process of pulp to the wafer baking oven steadily.
3.Capacity of this equipment will be 25 kgs of flour per batch which can be converted into about 65 kg batter pulp every time
4.Used to make batter to produce wafers
5.Constitutes a batter mixing tank, batter storage tank, pumps, and fittings for
transferring batter

Technical Data

Model	GGDL-T-8
Slurry Barrel Volume	95L
Beating Time	5-10mins
SUS304 Material Parts	Slurry barrel, cover, shell
SUS304 Thickness	More than 1.0mm
Food Touching Parts Material	SUS304
Water System	Automatic water control
Main Motor	3Kw
Slurry Pump Motor	0.75kw
Electric	380V, 50Hz, 3-phase
Dimension	1300660930mm
Weight	200kg
